Simulated Wearing Treatment Machine
Model :T448
Responsing Time:1 Working Days
Shipping Port:Shanghai
Payment Terms:T/T, L/C
Overview
Simulated wearing treatment machine/tester is to do pretreatment for mask&respirator samples which are for other performance test. By providing certain pre-conditioning procedure for tested samples, it brings a same test conditions for sample after simulating the real usage.
Standards
EN 149
Feature
- Touch screen control panel with English interface.
- PLC control system to provide stable test performance.
- Artificial lung provides certain breathing frequency.
Specification
| Item | Detail |
| Breathing frequency | 25 cycles/min |
| Breathing strength | 2L/stoke |
| Humidified air | 0.5-2.8L/min |
| Air flow | Adjustable |
| Condensation collection | Yes |
| Timer | Presetting |
| Power supply | 220V AC 50Hz |
| Dimension | 1050mm×750mm×1350mm 41.34inch×29.53inch×53.15inch |
| Net weight | 120 kg 264.5lb |
Configuration
| No. | Product |
| 2044801 | Simulated wearing treatment tester |
