Low Temperature Schildknecht Flexing Tester

Low Temperature Schildknecht Flexing Tester

Model :L165D
Responsing Time:1 Working Days
Shipping Port:Shanghai
Payment Terms:T/T, L/C
  • Low Temperature Schildknecht Flexing Tester
  • Low Temperature Schildknecht Flexing Tester

Overview

Low temperature Schildknecht flexing tester is professional designed for evaluation of fatigue performance under flexing in low temperature condition. It is aim to test the anti-cracks or anti-damage performance of coated materials for protective clothing, gloves at certain required test conditions.

Standards

ISO 7854, BS 3424-9, EN 14325, GB 24540

Feature

  • Stainless steel test chamber with viewing window is easy to observe the testing conditions.
  • Equipped automatic control system to provide stable test condition in the chamber.
  • Inching function to adjust the sample holder.

Specification

Item Detail
 Test position  10
 Stroke  11.7mm±0.35mm
 Speed  8.3Hz±0.4 (498±24r/min)
 Setting number  0-999999 (10000)
 Temperature range  -30℃ ~130℃
 Fluctuation  ±1℃
 Temp rise  4℃ /min
 Temp down  1℃ /min
 Material of inner chamber  SUS 304
Insulation material Hard PU foam
Control system PID control and PLC control
Test mode Programmable test mode
Touch screen One
Compressor Fully sealed compressor
Refrigerant R404A
Power 220V, 50/60 Hz

Configuration

No. Product
1216502 Low Temperature Schildknecht Flexing Tester
