Slip Resistance Tester

Slip Resistance Tester

Model :

L501
Responsing Time:1 Working Days
Shipping Port:Shanghai
Payment Terms:T/T, L/C
  • Product Details

Overview

Slip resistance tester is professional designed based on the method of test for the slip resistance of footwear. The tester can provide a certain force on the footwear to the surface which is simulating the floor. Then the tester provides two kinds of relative horizontal move. The frictional force and normal force will be measured automatically and the dynamic CoF will calculated by the system.

Standards

ISO 13287  GB/T 28287  SATRA TM144

Feature

  • Built-in computer with testing software will save more space and improve the convenience.
  • Changeable units of testing surface can meet different testing requirements.
  • Adjustable frame angle can realize the forward heel slip, backward forepart slip and flat slip.
  • Automatic calculation system will provide relative parameters.
  • Professional software make data storage, analysis and report export more convenient.

Specification

Item Detail
Vertical load Max 1000N
Horizontal load  Max 1000N
Sliding velocity Up to (1.3±0.03)m/s
Period time Preset 0-5s
Vertical sensor 1.25KN
Horizontal sensor  0.8KN×2
Testing rate 50-500mm/s
Language of software  Chinese or English
Testing surface Ceramic, wood, PVC, stainless steel or other specified materials
Power supply  220V 50Hz
Dimension  1910mm×670mm×1050mm
75.2inch×26.38inch×41.34inch
Net weight 295kg
650.36lb

Configuration

No. Product
1250101  Slip resistance tester
1250102 Silicon carbide paper
1250103 Glycerol
1250104 Detergent
